Integrated Test Bench 919

Generate Bosch 6,7,8,9,10-digit IQA code
Generate Denso 16,24,30-digit QR code
Generate Delphi C2i,C3i correction code
Generate Bosch piezo IMA, ISA code
Generate Siemens VDO-IIC code
Generate Cummins correction code

Standard Functions

Test actuator pump
Test piezo injector
Test solenoid valve injector
Test HEUI common rail injector
Test pump nozzle & unit pump
Test high-pressure common rail pump

Assist Functions

Flow sensor linear calibration
Oil nozzle opening pressure flow
Fuel tank oil level lower limit alarm
High pressure filter clogging reminder
Pump nozzle working pressure testing
Common rail pump plunger pressure curve

Optional Function

Test 4-pin injector
Testing X15,Q60 single pump
Testing Cummins HPI actuators
Test 4-6 injectors at the same time
Bosch 4-plunger common rail pump
Denso 4-plunger common rail pump

Hardware Configuration

Gear flow sensor
Dual DRV configuration
4 flow sensor metering units
Common rail pipe with filter function
Injection drive and system voltage monitor
Built-in oil actuated pump & high pressure common rail pump

Technical Parameters

Speed Control ModelFrequency Converter
Power3-Phase 4-Wire 380V 50/60HZ
Cooling SystemAir Conditioning (1P)
Rail Pressure0-2700 Bar
Rail Pressure Precision±5 Bar
Nozzle SensorGear Flow Sensor
Diesel Tank Volume40L Filtration Accuracy:3 μm
Oil Tank Volume20L Filtration Accuracy:5 μm
Fuel Temperature40±2℃
Filter Precision<5 μm
Dimensions2250*1170*1800 mm
Net Weight1260 kg
