Integrated Test Bench 916

OEM          Available

Payment               PayPal,Western Union,T/T

Place of Origin    China

Standard Functions

Test the piezo injector
Test solenoid valve injector
Test single pump and pump nozzle
Test high pressure common rail pump

Optional Functions

Test the 4-pin injector
Test X15,Q60 single pump
Test Cummins HPI actuators
Test Bosch 4-plunger common rail pump
Test Denso 4-plunger common rail pump

Assist Functions

Flow sensor linear calibration
Oil nozzle opening pressure flow
Fuel tank oil level lower limit alarm
High pressure filter clogging reminder

Hardware Configuration

Gear flow sensor 3pcs
Dual DRV configuration
Electronic measuring system
Common rail pipe with filter function
Injector drive and system voltage monitor

Technical Parameters

Speed Control ModelFrequency Converter
Power3-Phase 4-Wire 380V 50/60HZ
Cooling SystemAir Conditioning (1.5P)
Rail Pressure0-2700 Bar
Rail Pressure Precision±5 Bar
Nozzle SensorGear Flow Sensor 2 pcs
Fuel Pump SensorGear Flow Sensor 1 pc
Diesel Tank Volume40L Filtration Accuracy:3 μm
Oil Tank Volume20L Filtration Accuracy:5 μm
Fuel Temperature40±2℃
Dimensions1880*1100*1780 mm
Net Weight1135 kg
