1.Product Model
EDC 114
2.Product Application
EDC Test Bench Standard Injector used for Used to test all kinds of EDC Pumps including Bosch VP37 series, etc. on a diesel test bench.
3.Product Introduction
The EDC (Electronic Diesel Control) Test Bench Standard Injector is a piece of equipment used in diesel engine testing and calibration processes. EDC refers to the electronic control system used in diesel engines, which regulates fuel injection and other engine parameters for optimal performance and efficiency.
The Standard Injector Test Bench is designed to assess the performance and characteristics of diesel injectors under controlled conditions. It provides a platform for testing various aspects of injector operation, including fuel delivery rate, spray pattern, injection timing, and fuel atomization.
Features of EDC Test Bench Standard Injector
- Precision Control: The test bench allows precise control over injection parameters such as pressure, duration, and timing, enabling engineers to evaluate injector performance accurately.
- Data Acquisition: It typically includes data acquisition systems to record key parameters during testing, allowing for detailed analysis and comparison of injector performance.
- Calibration Capabilities: The test bench may offer calibration features to adjust injector settings for optimal engine performance and emissions control.
- Multiple Injector Compatibility: It can accommodate various types and sizes of injectors, making it versatile for testing different diesel engine configurations.
- Safety Features: Safety measures such as containment systems for fuel spills and pressure relief mechanisms are often incorporated to ensure safe operation during testing.
4.Product Model List
No. | Type | Bosch Number | Diameter(mm) |
---|---|---|---|
1 | Pintle | 681343009 | |
2 | 1688901000 | ||
3 | Hole | 1688901015 | φ0.4 |
4 | 1688901016 | φ0.5 | |
5 | 1688901017 | φ0.6 | |
6 | 1688901018 | φ0.7 | |
7 | 1688901019 | φ0.8 | |
8 | 1688901020 | φ0.6 | |
9 | Low-Inertia Hole | 1688901101 | φ0.6 |
10 | 1688901102 | φ0.6 | |
11 | 1688901103 | φ0.7 | |
12 | 1688901104 | φ0.7 | |
13 | 1688901105 | φ0.8 | |
14 | 1688901106 | φ0.8 | |
15 | 1688901109 | φ0.5 | |
16 | 1688901110 | φ0.5 |
